microWIOTYS, in partnership with WI6LABS
µWiotys is the perfect solution for:
Addressing industry and BMS (and many others)
with low afforts.
Adopting On The Shelf and easy solution with ModBus or Bacnet protocols over IP.
Benefiting from the experience of a company spcialized in industry and building management systems.
Connect a large set of devices, ready to connect (Built-in payload decoding), you can manage as bulks.
- µWiotys extend power of your equipment using LoRaWAN technology
According to ADEME (French Agency for Energy Transition), 70% of running SCADA are misused: systems are complex, control-command chain is inefficient. This malfunction leads to overconsumption of energy due to unsuitable heating instructions, bad lighting offset settings, etc.
- µWiotys is a “box“. It connects LoRaWAN equipment to SCADA applications. µWiotys helps facility manager improving SCADA performance and building owner keeping control of building stock.
- µWiotys is plug and play and compatible with most of PLC and other supervision. Most of LoRaWAN devices are already integrated to the solution.
Key Points for µWiOTYS
- Simple software architecture
- Easy configuration and integration
- Local solution : no cloud needed
- Business data decoding integrated
- Multibrand devices supported
- Bidirectional (remote control)
- One-shot license
- Custom and scalable network coverage
- Up-to 200 devices per gateway
Integrating µWIOTYS
- WI6LABS integrate Modbus stack or Bacnet stack in gateways to aggregate, structure and make available collected data. PLC interface easily to gateways and harvest data on gateway.
- Modbus library or Bacnet library are activated with license. There is one library license per gateway. LoRa Network server is integrated to gateways.
- Decoded data are also available on HTTP Rest Api or push to MQTT broker
- Data logger : data saved localy in CSV files
- µWiotys update and configuration is achieved thru FTP local connection
|
Necessary engineering skills
|
 |
|
Ability to dedicate resources for integration and maintenance
|
 |
|
Urgency of your project
|
 |
|
Challenges on Business Model
|
 |
Takeaway
In every case, gateways remain remotely manageable thanks to Kerlink’s ‘Wanesy Management Cockpit”, as part of our Maintain Program.
